OPTOKON

Data Network Equipment

OPTOKON connects businesses with its highly cost-effective and simple to deploy data network equipment. The large assortment provides outstanding value, high performance, and exceptional reliability. OPTOKON manufactures data network products specifically designed to help companies increase price-performance ratios and improve data management in virtualized environments.

Metalic SFP Transceivers

OPTOKON’s Copper Small Form Pluggable (SFP) transceivers are based on the SFP Multi Source Agreement (MSA). They are compatible with the Gigabit Ethernet standards as specified in IEEE 802.3. By default it is a full duplex device in preferred master mode with automatic crossover detection. The 10/100/1000 BASE-T operation requires an SGMII interface and 1000BASE-T module works with SERDES interface. Compact RJ 45 connector with fully metal enclosure, for lower EMI is RoHS compliant and lead-free.

SFP Transceivers - 155Mbps

The S155 series are hot pluggable 3.3 V Small-Form-Factor (SFP) duplex, Bidirectional and CWDM transceiver modules designed expressly for high speed communica¬tion applications that require rates of up to 155 Mbps. Transceivers are compliant with the Fast Ethernet, ATM, SONET OC 3/SDH STM 1 standards. The 155 Mbps transceivers are manufactured with LC receptacle that is compatible with the industry LC connector standard. All SFP transceivers have the digital diagnostic monitor feature.

SFP Transceivers - 1.25 Gbps

The 1.25 Gbps series are hot pluggable Small-Form-Factor (SFP) duplex, bidirectional and CWDM transceiver modules expressly designed for high speed communica¬tion applications that requiring rates of up to 1.25 Gbps. The transceivers are manufactured with LC receptacle that is compatible with the industry LC connector standard. All SFP transceivers have the digital diagnostic monitor feature.

SFP Transceivers - 3,125 Gbps

The 3.125 Gbps series are hot pluggable Small-Form- Factor (SFP) duplex, bidirectional and CWDM transceiver modules expressly designed for high speed communica- tion applications that requiring rates of up to 3.25 Gbps. The transceivers are manufactured with LC receptacle that is compatible with the industry LC connector standard. All SFP transceivers have the digital diagnostic monitor feature.

SFP Transceivers - 622 Mbps

The 622 Mbps series are hot pluggable Small-Form-Factor (SFP) duplex, bidirectional and CWDM transceiver modules expressly designed for high speed communica¬tion applications that requiring rates of up to 622 Mbps. The transceivers are manufactured with LC receptacle that is compatible with the industry LC connector standard. All SFP transceivers have the digital diagnostic monitor feature.

SFP Transceivers - 2.50 Gbps

The 2.50 Gbps series are hot pluggable Small-Form-Factor (SFP) duplex, bidirectional and CWDM and DWDM transceiver modules expressly designed for high speed communica¬tion applications that requiring rates of up to 2.50 Gbps. The transceivers are manufactured with LC receptacle that is compatible with the industry LC connector standard. All SFP transceivers have the digital diagnostic monitor feature.

SFP Transceivers 4.25 Gbps

The 4.50 Gbps series are hot pluggable Small-Form-Factor (SFP) duplex, bidirectional and CWDM transceiver modules expressly designed for high speed communica­tion applications that requiring rates of up to 4.50 Gbps. The transceivers are manufactured with LC receptacle that is compatible with the industry LC connector standard. All SFP transceivers have the digital diagnostic monitor feature.

SFP+ Transceivers - 10 Gbps

The OPTOKON transceivers are compliant with IEEE 802.3ae and the 10G MSA (Multi-Source Agreement). This upgrade, and reliability benefits by virtue of being hot-pluggable, also is designed for singlemode and multimode fiber with cost effective and high performance. The S10-D55, 1550 nm cooled EML laser based 10 Gigabit SFP+ transceiver is designed to transmit and receive optical data over single mode optical fiber for link length up to 100 km.

Copper SFP+ Transceivers RJ-SP-10GBASE-T

OPTOKON’s Copper Small Form Pluggable (SFP+) transceivers are based on the SFP Multi Source Agreement (MSA). They are compatible with the 10Gbase-T standards as specified in IEEE Std 802.3 . RJ-SP-10GBASE-T uses the SFP's RX_LOS(must be pulled up on host) pin for link indication. If pull up or open SFP's TX_DISABLE pin,  PHY IC be reset.

SFP+ Transceivers - 6 & 8 Gbps

The OPTOKON transceivers are compliant with IEEE 802.3ae and the SFP+ MSA. This upgrade, and reliability benefits by virtue of being hot-pluggable, also is designed for single-mode and multimode fiber with cost effective and high performance.

Active Optical Cable - 10G

Products developed the SFP+ to SFP+ Active Optical cable to provide an affordable, high-performance, low power approaches when connecting point-to-point or rack-to-rack. The SFP+ to SFP+ Active optical cable provide data rates of up to 11.1 Gbps and at distances of up to 300 meters. AOC is electrically hot-pluggable compliant to SFF-8431 and RoHS.

S10-SP- SFP+ to SFP+ passive cable assembly

Products developed the SFP+ to SFP+ copper patch cord to provide an affordable, high-performance, low power alternative to optical SFP+ approaches when connecting point-to-point or rack-to-rack. The SFP+ to SFP+ copper patch cords provide data rates of up to 10 Gbps and at distances of up to 7 meters. Short distance connections using optical cords can cost more than this copper solution.

SFP+ Transceivers – 6 Gbps

The OPTOKON transceivers are compliant with SFF-8432. This upgrade, and reliability benefits by virtue of being hot-pluggable, also is designed for single-mode and multimode fiber with cost effective and high performance. 6 Gbps SFP+ can be used for CIPRI (2.456, 4.915, 6.144 Gbps), LTE (4.915, 6.144 Gbps) or OBSAI (6.144 Gbps) applications.

QSFP CWDM Transceivers S40-QP-LR4-D

The S40-QP-LR4-10-D is designed to operate over single-mode fiber system using 4x10G CWDM channel in 1310 band and links up to 10km. The module converts 4 inputs channel of 10Gb/s electrical data to 4 CWDM optical signals, and multiplexes them into a single channel for 40Gb/s optical transmission. Reversely, on the receiver side, the module optically de-multiplexes a 40Gb/s input into 4 CWDM channels signals, and converts them to 4 channel output electrical data

QSFP Transceivers M40-V85-QP-SR-D

The M40-V85-QP-SR-D is designed to operate over multi-mode fiber system using 4x10G channels in 850 nm. They are compliant with the QSFP+ MSA and IEEE 802.3ba 40GBASE-SR4. The optical transmitter portion of the transceiver incorporates a 4-channel VCSEL (Vertical Cavity Surface Emitting Laser) array, a 4-channel input buffer and laser driver, diagnostic monitors, control and bias blocks. For module control, the control interface incorporates a Two Wire Serial interface of clock and data signals.

QSFP CWDM Transceivers S40-QP-LR4-XX-D

The S40-QP-LR4-XX-D is designed to operate over single-mode fiber system using 4x10G CWDM channel in 1310 band and links up to 30km. The module converts 4 inputs channel of 10Gb/s electrical data to 4 CWDM optical signals, and multiplexes them into a single channel for 40Gb/s optical transmission. Reversely, on the receiver side, the module optically de-multiplexes a 40Gb/s input into 4 CWDM channels signals, and converts them to 4 channel output electrical data.

Active Optical Cable - 40G

Products developed the QSFP QSFP Active Optical cable to provide an affordable, high-performance, low power approaches when connecting point-to-point or rack-to-rack. The QSFP to QSFP Active optical cable provide data rates of up to 11.1 Gbps and at distances of up to 150 meters. AOC is electrically hot-pluggable compliant to SFF-8431 and RoHS. Power dissipation < 1.5 W (per cable end)

Active optical cable – 40 Gbps to 4x 10 Gbps application

OPTOKON Active cable offers cost-effective solution for aggregate 4 discrete SFP+ channel into single parallel QSFP+ 40G interface. For typical applications, users can install this Active Optical cable between 40G QSFP port and four upstream 10Gbs SFP+ (Server Manufacturers supporting 40/10 Gbps or Data Center with 10 Gbps requirements with aggregation Architecture) and at distances of up to 150m.

X2 Transceiver 10 Gbps

The X2 transceiver module is a hot pluggable in the Z-direction module that is usable in typical router line card applications, storage, IP network and LAN and compliant to X2 MSA. The S10-D31-X2-LR is a fully integrated 10.3 Gbps optical transceiver module that consists of a 10.3 Gbps optical transmitter and receiver, XAUI interface, Mux and Demux with clock and data recovery (CDR).

CSFP Transceivers – 1.25 & 3.072 Gbps

OPTOKON’s transceivers are compatible with the Compact Small Form- Factor Pluggable (CSFP) Multi-Source Agreement (MSA) option 2, The transceiver consists of 2-channel Bi-directional Optical Transceiver unit with five sections: the LD driver, the limiting amplifier, the digital diagnostic monitor, type of laser (the DFB laser) and the PIN photo-detector. The optical output can be disabled by a TTL logic high-level input of Tx Disable, and the system also can disable the module via I2C. Tx Fault is provided to indicate that degradation of the laser. Loss of signal (LOS) output is provided to indicate the loss of an input optical signal of receiver or the link status with partner. The system can also get the LOS (or Link)/Disable/Fault information via I2C register access. Conventional SFP will function when plugged into a C-SFP socket, at the same time no damage to C-SFP and host board if C-SFP module is plugged into a conventional SFP socket


XFP Transceivers – 10 Gbps

The OPTOKON Small Form Factor 10Gb/s (XFP) transceivers are compliant with the current XFP Multi-Source Agreement (MSA) Specification. Digital diagnostics functions are available via a 2-wire serial interface, as specified in the XFP MSA. The transceiver is RoHS compliant and leads free per Directive 2002/95/EC

CFP2 Transceivers - 100 Gbps

OPTOKON CFP2 transceivers is designed for high speed communica¬tion applications that requiring rates of from 103.125 to 111.81 Gbps. The transceiver converts 4 inputs channel of 25,78 Gb/s to 27.95 electrical data to 4 CWDM optical signals, and multiplexes them into a single channel through an industry standard LC connector. CFP2 transceiver has the Digital Diagnostic Monitor Feature.

CFP4 Transceivers - 100 Gbps

OPTOKON CFP4 transceivers is designed for high speed communica¬tion applications that requiring rates of from 103.125 to 111.81 Gbps. The transceiver converts 4 inputs channel of 25,78 Gb/s to 27.95 electrical data to 4 CWDM optical signals, and multiplexes them into a single channel through an industry standard LC connector. CFP4 transceiver has the Digital Diagnostic Monitor Feature.

QSFP28 Transceivers – 100Gbps LR4

OPTOKON QSFP28 transceivers is designed for high speed communica¬tion applications that requiring rates of from 103.125 to 111.81 Gbps. The transceiver converts 4 inputs channel of 25.78 to 27.95 Gb/s electrical data to 4 CWDM optical signals, and multiplexes them into a single channel through an industry standard LC connector.

QSFP28 Transceivers – 100Gbps SR4

OPTOKON QSFP28 transceivers is designed for high speed communica¬tion applications that requiring rates of from 103.125 to 111.81 Gbps. The optical transmitter portion of the transceiver incorporates a 4-channel VCSEL 850 nm over multimode fiber.

SFP28 Transceivers

The 28 Gbps series are hot pluggable modules expressly designed for high speed communica¬tion applications that requiring rates of up to 28 Gbps. The transceivers are manufactured with LC receptacle that is compatible with the industry LC connector standard. All SFP28 transceivers have the digital diagnostic monitor feature.

Active Optical Cable – 28 Gbps

SFP28 Active Optical cable to provide an affordable, high-performance, low power approaches when connecting point-to-point or rack-to-rack. The SFP28 to SFP28 Active optical cable provide data rates of up to 28 Gbps and at distances of up to 100 meters on OM3 Multimode fiber. AOC is electrically hot-pluggable compliant to SFF-8431 and RoHS. Power dissipation < 1.5 W (per cable end).

GPON Optical Line Terminal (OLT)

GPON interfaces are used to connect the optical distribution network (PON). You can connect up to 128 subscriber optical terminals via a single fibre for each interface. Access to the operator's transport network is provided through 10 Gigabit or combined Gigabit uplink interfaces. OLT LTP allows the operator to build scalable, fault tolerant "last mile" networks to ensure the highest safety standards. OLT manages subscriber devices, traffic switching and connection to the transport network. Broadband access using FTTH technology is the highest quality version of the Triple Play service delivery, as it provides high data rates over long distances. The main advantage of PON technology is the lack of electrically powered active nodes within the section from OLT to ONT, which greatly reduces the network operating cost. What's more, PON technology saves on cabling infrastructure by reducing the total length of the optical fibre, as only one fibre for a group of up to 128 subscribers is used within the section from the central node to the splitter. OLT LTP support 2 hot-swappable redundant power units.


OLT MA4000-PX GPON Optical Line Terminal

Multi-service access and the aggregation node MA4000-PX allows to construct access networks based on GPON technology. OLT usage allows an operator to construct scalable, failsafe "last mile" networks, ensuring high safety requirements in either urban or rural areas. OLT controls customer stations, traffic switching and transport network access. A core element of the MA4000-PX is a scalable Ethernet L2+ switch (PP4X) that interacts with optical interface access modules PLC8 to connect customer devices via GPON technology.

Design features
Modules are installed in a standard 19" 9U Eurocase. The 9U case has two slots available to install PP4X switch circuit control modules and 16 slots for linear PCL8 modules (GPON). A single system can have one or two PP4X central switch control modules. Installation of two modules improves the fault-tolerance due to switch redundancy and improves the bandwidth capacity of the system due to the distribution of data streams between modules via stacking.

NTU-SFP-100 GPON subscriber terminal, SFP form factor

The device NTU-SFP-100, high-performance mobile terminal, designed for communication with higher-level equipment of passive optical networks and broadband access services to the end user.
Connection with GPON networks is provided via PON interface. SFP or SFP + interfaces are for connecting customer’s end equipment.

NTU-SFP-100 allows to receive and process untagged or once tagged traffic. The number of services are restricted by OLT opportunities. NTU-SFP-100 can operate in bridge mode (bridge).


ONT NTU-RG-5421G-Wac GPON User terminal

NTU series ONT – high performance multifunctional subscriber terminals that are designed to access modern telephony, IPTV, OTT services as well as high-speed Internet.
Furthermore, NTU-RG terminals allow carriers to offer their clients a wide range of services ad opportunities to work ina local network.


Access Ethernet switches MES1124M, MES1124MB, MES2124M, MES2124MB

MES access switches are managed level L2 switches with 24 10/100/1000Base-T ports and dual 1000Base-T/Base-X ports. Switches provide end users' connection to the network at large enterprises, small and medium-sized businesses and to networks of mobile communication operators with the help of the Fast and Gigabit Ethernet interfaces. The functionality of the switch include physical stacking, VLAN and multicast distribution groups support, as well as advanced security features.

Access Ethernet switches MES2308x

MES2308х series access switches are managed L2+ switches with 10 ports of 10/100/1000BASE-T (on MES2308P 8 out of 10 ports support PoE/PoE+) and 2 ports of 10/100/1000BASE-X (SFP). The switches are designed to connect end users to largescale corporate network, small and medium business networks and to the service provider networks using Gigabit Ethernet interfaces. The switches support physical stacking, VLAN, multicast groups and advanced security functions.

Access Ethernet switches MES23xx

New generation of MES access switches provides end users connection to a large-scale corporate network, small and medium business networks and to a service provider networks using 1G/10G interfaces.

The switches support physical stacking, VLANs, multicast groups and advanced security functions.

Aggregation Ethernet switches MES3348 + MES3348F

MES3348(F) switches can be used in service provider network as the aggregation or transport switches. They have a high performance with interfaces operating at speeds of 10 Gbps or 1 Gbps. The features’ set of MES3348(F) includes L3 functions, static routing, dynamic routing, 4 SFP+ 10 Gbps interfaces, stack up to 8 devices, redundant and hot swappable power supplies.

Ethernet  Ring  Protection  Switching  (ERPS)  protocol provides fast convergence (less than 200 ms) of the network, that guaranties uninterrupted service.


Aggregation Ethernet switches MES33xx

MES33xx series switches can be used in service provider networks as aggregation or transport switches. They have a great margin of performance due to universal interfaces operating at speeds of 10Gbps or 1Gbps.
The features list of MES aggregation switches includes advanced L2 functions, static and dynamic routing, four 10 Gbps (SFP+) interfaces, stacking up to 8 devices and hotswappable redundant power supplies.

Aggregation Ethernet switches MES5324

MES5324 switches are high performance devices with 10GBASE-R and 40GBASE-SR4/LR4 interfaces that can be used as aggregation or transport switches in carrier networks and as Top-of-Rack or End-of-Row switches for data centers. The non-blocking architecture guarantees lossless packet forwarding at wire speed with minimum and predictable delays for all types of traffic. The front-to-back cooling provides effective cooldown in modern data centers. The redundant and hot-swappable fans and AC/DC power supplies with advanced hardware monitoring functions provide high reliability and uninterrupted services.

Aggregation Ethernet switches MES53xxA

MES5316A, MES5324A, MES5332A switches are high performance devices with 10GBASE-R/1000BASE-X that can be used as aggregation switches in carrier networks and small data centers.
The devices support operating bandwidth of 1 Gbps (SFP) and 10 Gbps (SFP+) that provides flexible using and ability of smooth transition to higher data rates. The non-blocking architecture guarantees lossless packet forwarding at high loads with minimum and predictable delays for all types of traffic.

The front-to-back cooling provides effective cooldown in modern data centers.

The redundant and hot-swappable fans and AC/DC power supplies with advanced hardware monitoring functions provide high reliability and uninterrupted services.



NTU-SFP-100 GPON subscriber terminal, SFP form factor

The device NTU-SFP-100, high-performance mobile terminal, designed for communication with higher-level equipment of passive optical networks and broadband access services to the end user.
Connection with GPON networks is provided via PON interface. SFP or SFP + interfaces are for connecting customer’s end equipment.

NTU-SFP-100 allows to receive and process untagged or once tagged traffic. The number of services are restricted by OLT opportunities.

NTU-SFP-100 can operate in bridge mode (bridge).


Data center switch MES5448

The MES5448 switch provides full Layer 2 and Layer 3 functionality for carrier networks and data centers. The MES5448 meets the DC requirements for Top-of-Rack and End-of-Row switches and requirements of service provider for aggregation and backbone networks, providing high performance and cost-effective solution.

The non-blocking architecture guarantees lossless packet forwarding at wire speed with minimum and predictable delays for all types of traffic. The front-to-back cooling provides effective cooldown in modern data centers. The redundant and hot-swappable fans and AC/DC power supplies with advanced hardware monitoring functions provide high reliability and uninterrupted services.

ACS Automatic Configuration Server

Automatic Configuration Server (ACS) is intended to simplify and automatise configuration of subscriber devices (CPE) by using the protocol described in TR-069 standard and allows operators to use global network for centralised control over customer equipment. The standard defines a mechanism of safe CPE automatic configuration and combines CPE control functions in a single system.

Ethernet switches MES2324P and MES2348P

MES23xxP series access switches - managed L2+ switches which have 24/48 ports of 10/100/1000BASE-T with PoE/PoE+ support and 4 ports of 10GBASE-R (SFP+)/1000BASE-X (SFP). The switches are designed to connect end users to a largescale corporate network, small and medium business networks and to a service provider networks using 1G/10G Ethernet interfaces. The switches support physical stacking, VLANs, multicast groups and advanced security functions.

EMS Centralized Managing Network System

The EMS introduces a centralized management system of network equipment produced by OPTOKON, a.s. The system is based on client-server architecture. The single access server provides a Web interface allowing independent and simultaneous control over different network elements.

ONT GPON NTU subscriber terminals

NTU series ONT - high performance multifunctional subscriber terminals that are designed to access modern telephony, IPTV, OTT services as well as high-speed Internet. Furthermore, NTU-X subscriber terminals allow carriers to offer their clients a wide range of services and opportunities to work in a local network.

User terminals ONT GPON NTU-1(C)

ONT NTU-1(C) - user terminals that intended to connect users to data network based on GPON technology.

Industrial switches MES3508 + MES3508P

MES3508 and MES3508P industrial switches by OPTOKON are designed to organize secure fault-tolerant networks on sites with high requirements to temperature, vibrations, mechanical impact, etc. The switches have 10/100/1000BASE-T with PoE/PoE+1 support and Combo ports of 10/100/1000BASE-T/1000BASE-FX for optional connection fiber or cooper cable.


Wireless access point WEP-2ac Enterprise class

Solution for businesses
WEP-2ac provides high-speed, secure, affordable and easyto-use wireless network that combines a variety of features and services needed for corporate clients. WEP-2ac will become a universal solution for setting up a wireless network with a large number of users and high traffic (office, government offices, conference rooms, laboratories, hotels, etc.).


WOP-2ac Wi-Fi Enterprise Access Point

Outdoor Access Point
WOP-2ac provides high-performance and safe wireless connection that combines numerous features and services absolutely necessary for convenient network access in crowded areas. WОP-2ac is a proper solution for organization of wireless networks in various climatic conditions in a wide range of operating temperatures and high humidity (in parks, at factories, stadiums, etc.) and provides an optimal platform for communication networks organization in suburban settlements and remote locations.

WB-2P-LR5 Wireless User Station

WB-2P-LR5 - a high-performance wireless user station designed for up-to-date high speed service provision via Wi-Fi technology.

Wireless Connection
WB-2P-LR5 is developed for connection to Wi-Fi access network which might be constructed using base stations within long distances.
Easy Management via ACS
The ACS autoconfiguration system based on TR-069 protocol provides service providers with convenient functionality for management of firmwares and user stations’ configuration. The ACS loads an individual configuration to the device automatically according to the subscriber account data. The intellectual update of the firmware operates with devices on a network in a row, updating a group of devices according to the set queue. The ACS system includes NorthBoundInterface (NBI) for interfacing with OSS complexes.
Performance
To ensure a stable and uninterrupted operation, the device is equipped with high-performance processors providing high routing rates and ensuring the effective operation of FBWA (Fixed Broadband Wireless Access) technology.

WEP-12ac Wireless Indoor Access Point

Solution for Enterprises
WEP-12ac provides high-speed, safe, accessible and easy-to-use wireless network which combines many features and services needed for corporate clients. WEP-12ac will become a universal solution for organizations of a wireless network with a large number of users and high traffic (office, public institutions, conference rooms, laboratories, hotels, etc.).
Wireless Wi-Fi connection
With the support of the standard IEEE 802.11ac Access point WEP-12ac delivers transfer speed up to 1 Gbit/s. The device has a key advantages of technology BEAMFORMING - to dynamically change the radiation pattern of antennas, so that optimum coverage hotspot adjust to the current location of the user. Use of the six dual-band antennas and large radius coverage (up to 200 m) make it possible to WEP-12ac - universal access point for organizations of the corporate network.
Security
For corporate environment, there are modern technology authentication and encryption provide protection and security of personal data of the corporate environment. In a corporate environment uses dynamic key which is individual for each client of running at the moment.
Power
Support PoE technology allows installation equipment in any place, regardless of the location of power supplies, economizes on the cost of powercables makes installation easy and time-consuming. When using sequential circuit connecting devices "point to point" supply is provided by the AC power adapter or separate power cable.

WOP-12ac Wi-Fi Enterprise Access Point

Outdoor Access Point
WOP-12ac provides high-performance and safe wireless connection that combines numerous features and services absolutely necessary for convenient network access in crowded areas. WОP-12ac is a proper solution for organization of wireless networks in various climatic conditions in a wide range of operating temperatures and high humidity (in parks, at factories, stadiums, etc.) and provides an optimal platform for communication networks organization in suburban settlements and remote locations.

Solutions Scalability
The WОP-12ac wireless access point is a new flexible solution that allows you to change the network coverage in order to increase the quantity of serviced mobile devices. Due to high-performance hardware platform, scalability features, and understandable interface, it is possible to set up wireless IT infrastructure simply and fast.
Wireless Connection
The WOP-12ac provides 1300 Mbps (5GHz) + 450 Mbps (2.4 GHz) data rate as it supports IEEE 802.11n/ac standards.Furthermore, the WOP-12ac supports MIMO technology and has omnidirectional antennas that makes it a universal solution for public networks organization.
Security
The WOP-12ac provides secure connection due to the support of up-to-date authentication technologies. Particularly, it uses a dynamic key that is unique for each mobile device that interacts with WOP-12ac.
Performance
To ensure a stable and uninterrupted operation, the device is equipped with high-performance Broadcom chipsets providing top data processing rates.
Power Supply
The PoE+ technology makes it possible to install the equipment virtually anywhere, regardless of the power supply location, reduce total cost by discarding power cables and perform the installation easier and faster.
