The 2.5 Gbps series are hot pluggable Small-Form-Factor (SFP) duplex, bidirectional and CWDM and DWDM transceiver modules expressly designed for high speed communication applications that requiring rates of up to 2.5 Gbps. The transceivers are manufactured with LC receptacle that is compatible with the industry LC connector standard. All SFP transceivers have the digital diagnostic monitor feature.
SFP Transceivers – 2.5 Gbps
- Hot pluggable Small-Form-Factor (SFP) duplex
- Bidirectional and CWDM and DWDM transceiver modules
- Rates of up to 2.5 Gbps
- Digital diagnostic monitor feature
|
|
Unit |
SX |
LRM |
LX |
HX |
ZX |
UX |
|
Average output power (min / max) |
dBm |
-10 / -3 |
-9 / -3 |
-5 / 0 |
-2 / 3 |
0 / 5 |
0 / 5 |
|
Receiver sensitivity |
dBm |
-18 |
-18 |
-19 |
-19 |
-26 |
-30 |
|
Overload |
dBm |
-3 |
-3 |
0 |
0 |
-9 |
-10 |
|
Maximum distance |
km |
0.550 |
2 |
20 |
40 |
80 |
120 |
|
Fiber type |
- |
MMF |
SMF |
SMF |
SMF |
SMF |
SMF |
|
Optical link budget |
dBm |
8 |
9 |
14 |
17 |
26 |
30 |
|
Wavelength / laser type |
nm |
850 / VCSEL |
1310 / FP |
1310/DFB |
1310 / DFB 1550 / DFB |
1550 / DFB |
1550 / DFB |
Table 1: Basic technical specifications according to distance.
For high speed communication applications
ACT_32-12_EN-SFP-2.5G
