The OPTOKON transceivers are compliant with IEEE 802.3ae and the 10G MSA (Multi-Source Agreement). This upgrade, and reliability benefits by virtue of being hot-pluggable, also is designed for single-mode and multi-mode fiber with cost effective and high performance. The S10-D55, 1550 nm cooled EML laser based 10 Gigabit SFP+ transceiver is designed to transmit and receive optical data over single mode optical fiber for link length up to 100 km.
SFP+ Transceivers – 10 Gbps
Temperature:
OPTOKON is always trying to satisfy as much market demand as possible and with this in mind, almost all OPTOKON SFP transceivers are manufactured in the Commercial, Extended and Industrial temperature ranges to provide you all possibilities you need for your application.
Safety and regulatory compliance:
| Electrostatic discharge (ESD) Electromagnetic Interference (EMI) Laser Eye Safety Component Recognition ROHS EMC |
IEC/EN 61000-4-2 FCC Part 15 Class B EN 55022 Class B (CISPR 22A) Class 1 laser product IEC/EN 60950, UL 2002/95/EC EN 61000-3 |
|
|
Unit |
SR |
LRM |
LR02 |
LR |
LR20 |
ER |
ER60 |
ZR |
ZR+ |
|
Average output power (min / max) |
dBm |
-6 / -1 |
-6.5 / 0.5 |
-8.2 / 0.5 |
-6 / -0.5 |
-6 / -0.5 |
-1 / 4 |
0 / 5 |
0 / 5 |
1 / 5 |
|
Receiver sensitivity |
dBm |
-10 |
-10 |
-14.4 |
-14.4 |
-15 |
-16 |
-20 |
-23 |
-25 |
|
Overload |
dBm |
0.5 |
1.5 |
0 |
0 |
0,5 |
0 |
0 |
-7 |
-6 |
|
Maximum distance |
km |
0.330 |
0.220 |
2 |
10 |
20 |
40 |
60 |
80 |
100 |
|
Fiber type |
- |
MMF |
MMF |
SMF |
SMF |
SMF |
SMF |
SMF |
SMF |
SMF |
|
Optical link budget |
dB |
4 |
3.5 |
6.2 |
8.4 |
9 |
15 |
15 |
23 |
26 |
|
Wavelength / laser type |
nm |
850 / VCSEL |
1310/FP |
1310/FP |
1310/DFB |
1310/DFB |
1310/DFB 1550/EML |
DFB |
1550/ |
1550/ |
Table 1: Basic technical specifications: optical power budget according to distance
- 10G Ethernet
- CPRI 8
- 10G Fiber Channel
ACT_02-13_EN-SFP+
