The LSH adapters are designed for connectors with PC and APC polishing method. The integrated LSH protective cap protects the ferrule from dust and prevents laser light emission. The simplex version is equipped with an internal metal shutter. The LSH adapters are available in simplex or duplex versions. The dimensions of the new single adapter are the same as the SC type. The same standardized cut-outs will then be used for all adapters which are compatible with SC standard. Duplex compact adapters can be color-coded by exchangeable clips.
LSH adapters
- Material PBT / UL 94 V-0.
- Integral self-closing metal/plastic laser protection flaps
- Zirconia (ceramic) alignment sleeve
- Semi-transparent plastic dust cover
- In acc. with IEC 61754-15 and EN 50377-8
- Compatible with E-2000TM standard
| Delta insertion loss: | ≤ 0.1 dB (grade B) (testing method acc. to IEC 61300-3-42) |
|---|---|
| Mating cycles: | min. 500 |
| Sleeve Pull force: | 2 - 6 N |
| Oper. temperature: | -40 to +85 °C |
- Telecom
- LAN, WAN
- CATV
- Railway applications
ADP_03-01_EN-LSH_adapters
